Laboratory Products
The Super Screw
Telescopic Maxillary Expander
ONE EXPANDER DOES IT ALL
Friction Coated: eliminates back turning due to tongue action
and is GUARANTEED to activate
Innovative Telescopic design expands a full 18mm/0.7.
Never remake an appliance or compromise a result
Activation from the front of the mouth: activation with a
familiar hex wrench which is safer and easier to use
A true 16mm/0.62 or 12mm/0.47 closed length:
attachment wires are perpendicular to expansion axis,
resulting in a true 16mm/0.62 closed length
Graduated scale: direct read-out of expansion enhances
communication between orthodontist and parent.
Each line represents 2mm/0.08 of expansion
Expansion limit Indicator: warning threads appear when
18mm/0.7 is reached, eliminating guessing at how much
expansion is left
Versatile: the SUPER Screw can be fabricated for
Hygienic, Acrylic Type (Haas) or Bonded applications.
Use in cases requiring little expansion, to those needing the
most expansion
Latest Technology: laser soldered and welded for perfect
joints. 316 stainless steel construction and rolled threads.
Optional Lock-Nut: for securing the appliance after
activation is completed.
Great patient comfort: small size (12mm/0.47) with its
rounded smooth shape allows the SUPER Screw to have a
smaller profile and fit higher in the palate.
Most hygienic of any appliance. The rounded, smooth shape
offers no traps for food, making it exceedingly easy to clean
SPECIFICATIONS: Internally coated with nylon for friction enhancement.
Closed length with optional lock-nut -17.5mm/0.68.
Maximum expansion - 18mm/0.7. One complete turn - 1mm/0.039.
Activates with a hex wrench. Activation from front of the mouth.
Triple telescopic design. Can be turned back to release pressure.
Sterilisation by any standard method.
Universal wrench for optional lock-nut.
Size
Expansion
O/No
Mini Super Screw
12mm/0.47
12mm/0.47
1116
Regular Super Screw
16mm/0.7
18mm/0.7
1115
Locking Nut and Wrench
1117LN
